Northern Package-Freestanding

Economy Greenhouse Packages

Its engineered design is the secret. Our design team starts with Allied's Gatorshield 50,000 PSI, galvanized structural steel tubing. It's made for maximum performance in greenhouse design. Gatorshield averages 42% stronger and 15% lighter than Schedule 40 pipe. Still, tubing is tubing. It's the design that makes the difference. Nothing is used that will weaken your frame and cause it to fail when you need it the most! These packages were developed to provide a complete greenhouse, ready to move into. All you need to add is benches and a few other growing accessories to match the plants you will be growing.

*Metal endwalls are made of 1-1/2" square tubing. Metal ends are field-cut to fit required equipment and are attached with exclusive endwall connectors.

*** Purlins : 3 runs 1.315" x 18 ga. Galv. Steel Purlins (Standard)

**Customer must provide treated lumber for endwall framing and base boards. Treated lumber should be used for best results. Optional metal endwalls eliminate the need for endwall lumber. Freight charges additional.

Back to Greenhouse Package main page

Options
Pricing
Specifications
Support
Accessories

Options

System E1445 - 14' x 45'
System E1495 - 14' x 95'
System E2245 - 22' x 45'
System E2295 - 22' x 95'
System E2845 - 28' x 45'
System E2895 - 28' x 95'
System E3045 - 30' x 45'
System E3095 - 30' x 95'

Pricing

System E1445 - 14' x 45' Package
Complete 14' x 45' frame** with 1-5/8" bows and 5' bow spacing. 630 sq ft. (4' bow spacing available at additional cost) Double layer , inflated, 4 yr 6mil poly film cover Quick Clip poly attachment system One heavy duty storm door One 24" 2-speed, 1/2 HP exhaust fan Two 33" motorized intake shutter 60,000 BTUH heater with vent pipe and heater hanger One 20" Uni-Flo HAF fans All necessary thermosta
Model#	Size	Price	Buy Now
System E1445 Package	14' x 45'- 5' bow spacing	$11,720	Call to Order
Options Metal Endwall for polyethylene ends $695.00/pair Metal Endwall for polycarbonate ends $1095.00/pair Northern Upgrade to E1448 (4' bow spacing) $895.00 /Pair 8mm Twinwall polycarbonate endwalls $1795.00
System E1495 - 14' x 95' Package
Complete 14' x 95' frame** with 1-3/8" bows and 5' bow spacing. 1330 sq ft. (4' bow spacing available at additional cost) Double layer , inflated, 4 yr 6mil poly film cover Quick Clip poly attachment system One heavy duty storm door One 36" 2-speed, 1/2 HP exhaust fan Two 39" motorized intake shutter 115,000 BTUH heater with vent pipe and heater hanger Two 20" Uni-Flo HAF fans All necessary thermosta
Model#	Size	Price	Buy Now
System E1495 - 14' x 95'	14' x 95'- 5' bow spacing	$14,395	Call to Order
Options Metal Endwall for polyethylene ends $695.00 /pair Metal Endwall for polycarbonate ends $1098.00 /pair Northern Upgrade to E1448 (4' bow spacing) 1790.00 8mm Twinwall polycarbonate endwalls $1795.00
System E1495 - 22' x 45' Package
Complete 22' x 45' frame** with 1-5/8" bows and 5 ft. bow spacing. 990 sq. ft. (4ft bow spacing available at additional cost) Double layer , inflated, 4 yr 6mil poly film cover Quick Clip poly attachment system One heavy duty storm door One 36" 2-speed, 1/2 HP exhaust fan One 27" motorized gable shutter Two 39" motorized intake shutter 90,000 BTUH heater with vent pipe and heater hanger Two 20" Uni-Flo HAF fans All necessary thermosta
Model#	Size	Price	Buy Now
System E2245 - 22' x 45' '	22' x 45'- 5' bow spacing	$17,483	Call to Order
Options Metal Endwall for polyethylene ends $1,195.00 /pair Metal Endwall for polycarbonate ends $2,095.00 /pair Northern Upgrade to E2248 (4' bow spacing) 1,364.00 8mm Twinwall polycarbonate endwalls $2,550.00
System E2295 - 22' x 95'
Complete 22' x 95' frame** with 1-5/8" bows and 5 ft. bow spacing. 2090 sq. ft. (4ft bow spacing available at additional cost) Double layer , inflated, 4 yr 6mil poly film cover Quick Clip poly attachment system One heavy duty storm door One 36" 2-speed, 1/2 HP exhaust fan One 36" 1-speed, 1/2 HP exhaust fan One 33" motorized gable shutter Two 51" motorized intake shutter 175,000 BTUH heater with vent pipe and heater hanger Four 20" Uni-Flo HAF fans All necessary thermosta
Model#	Size	Price	Buy Now
System E2295 - 22' x 95' '	22' x 95'- 5' bow spacing	23,595,00	Call to Order
Options Metal Endwall for polyethylene ends $1,195.00 /pair Metal Endwall for polycarbonate ends $1,595.00 /pair Northern Upgrade to E2296 (4' bow spacing) $2,784.00 8mm Twinwall polycarbonate endwalls $2,550.00
System E2845 - 28' x 45'
Complete 28' x 45' frame** with 1-5/8" bows and 5 ft. bow spacing. 1260 sq. ft. (4ft bow spacing available at additional cost) Double layer , inflated, 4 yr 6mil poly film cover Quick Clip poly attachment system One heavy duty storm door One 36" 2-speed, 1/2 HP exhaust fan One 33" motorized gable shutter Two 39" motorized intake shutter 115,000 BTUH heater with vent pipe and heater hanger Two 20" Uni-Flo HAF fans All necessary thermosta
Model#	Size	Price	Buy Now
System E2845 Package	28' x 45'- 5' bow spacing	$18,705	Call to Order
Options Metal Endwall for polyethylene ends $1,395.00 /pair Metal Endwall for polycarbonate ends $1,595 /pair Northern Upgrade to E2848 (4' bow spacing) 1995.00 8mm Twinwall polycarbonate endwalls $2,595.00
System E3045 - 30' x 45'
Complete 30' x 45' frame** with 1-5/8" bows and 5 ft. bow spacing. 1350 sq. ft. (4ft bow spacing available at additional cost) Double layer , inflated, 4 yr 6mil poly film cover Quick Clip poly attachment system One heavy duty storm door One 42" 2-speed, 3/4 HP exhaust fan Two 3' x 5' motorized gable shutters One 39" motorized intake shutter 115,000 BTUH heater with vent pipe and heater hanger Two 20" Uni-Flo HAF fans All necessary thermosta
Model#	Size	Price	Buy Now
System E3045 Package	30' x 45'- 5' bow spacing	$28,130	Call to Order
Options Metal Endwall for polyethylene ends $1,695.00 /pair Metal Endwall for polycarbonate ends $1,995.00 /pair Northern Upgrade to E3048 (4' bow spacing)$1,995 8mm Twinwall polycarbonate endwalls $2,950.00
System E3095 - 30' x 95'
Complete 30' x 95' frame** with 1-5/8" bows and 5 ft. bow spacing. 2850 sq. ft. (4ft bow spacing available at additional cost) Double layer , inflated, 4 yr 6mil poly film cover Quick Clip poly attachment system One heavy duty storm door One 42" 2-speed, 3/4 HP exhaust fan One 42" 1-speed, 3/4 HP exhaust fan One 39" motorized gable shutter Two 57" motorized intake shutter 230,000 BTUH heater with vent pipe and heater hanger Four 20" Uni-Flo HAF fans All necessary thermosta
Model#	Size	Price	Buy Now
System E3095 Package	30' x 95'- 5' bow spacing	$29,755	Call to Order
Options Metal Endwall for polyethylene ends $1,695.00 /pair Metal Endwall for polycarbonate ends $1,995.00 /pair Northern Upgrade to E3048 (4' bow spacing)$3,990 8mm Twinwall polycarbonate endwalls $2,950.00

Specifications
Support

If you need additional technical support or have a question, we can be reached 8:30 AM to 5:30 PM central time, Monday through Friday at:

Phone: 800-531-4769 (toll-free US and Canada) or 251-471-5328

FAX: 251-471-5465

E-mail: info@gothicarchgreenhouses.net
Accessories

Recommended Accessories

Poly Film: Choose from 1-year or 4-year, 6mil poly covering. Available in clear or white.
Call for volume purchases.

>> More information

Poly Patch Tape: Poly Patch is the leading film repair tape in America. A complete first-aid kit for greenhouses, this easy-to-use patching tape bonds aggressively to polyethylene film.

Call for volume purchases.

Wiggle Wire™ poly attachment system: Used on thousands of greenhouses, Wiggle Wire has proven to be a low-cost, effective system to attach polyethylene or shade material to greenhouses. Quick and easy to use, the Wiggle Wire attachment system requires no tools.

P01-WIGLWIRE 6-foot stainless steel Wiggle Wire

P01-WIGLWIRE 6-foot stainless steel Wiggle Wire

Galvanized End Frame Packages: Optional galvanized end frame kit speeds set up and eliminates the need for any lumber. Heavy-duty swinging door includes 8mm clear polycarbonate sheeting.

Galvanized End Frame Package
Galvanized end frame with door: 14' (3' x 6'-8") 16', 18' or 20' (4' x 6'-8")
