Glazing Systems
We offer four different glazing systems: single pane glass, double tempered insulated glass, twinwall polycarbonate, and fivewall polycarbonate. Our glazing options allow you to attain the best balance between insulating value, aesthetics, and economy to suit your needs.
Single layer Glass:
Our single glass is tempered safety glass to minimize any possibility of breakage or injury. The traditional look appeals to greenhouse gardens with full light transmission capable of controlling their growing variable. Single pane glass is adequate for keeping a `cool greenhouse` in mild climates.
R value = 0.9.
Approximately 95% light transmission
Double Layer Insulated Glass:
Our double glazed glass is tempered safety glass to minimize any possibility of breakage or injury. Insulated double glass is the best of both worlds, providing you with the aesthetically pleasing look of glass and the insulation you may require for your specialty plants.
Typical clear double glass R Value = 2.04
Approximately 90% light transmission
Low E glass
Double glaze glass can also be upgraded to a high-performance Low E glass to help keep the greenhouse even cooler in the summer and warmer in the winter while still maintaining the light necessary for plant growth. Other high performance options are available, please contact us for more information.
Optional high performance Low E glass R Value = 3.3
Approximately 70% light transmission
Twinwall Polycarbonate:
Our 6mm twinwall polycarbonate is the most economical glazing materials. It is a practical for a `growing greenhouse` as it offers 50% more insulation than single pane glass and diffuses harmful sunlight in the summer. It is essentially unbreakable, making it very safe in a family environment. The insulation will prevent the temperature in the greenhouse from changing drastically and results in the best possible growing environment.
R value = 1.59.
Approximately 82% light transmission.
Fivewall Polycarbonate:
Our new 16mm fivewall polycarbonate offers unbeatable insulation which is 50% more insulating than double pane glass, or 80% more efficient than 6mm or 8mm twinwall polycarbonate. Fivewall is ideal for colder climates, gardeners who grow specialty plants, or for those who prefer the most energy efficient greenhouse to reduce heating costs.
R value = 3.03.
Approximately 62% light transmission
-
Pricing
| Item # |
Description |
Green/Brown and White |
Buy Now |
| B06-PLT-812 SG |
8'3" x 12'5" |
$ |
Call to Order |
| B06-PLT-1012 SG |
10'3" x 12'5" |
-- |
Call to Order |
| B06-PLT-1220 SG |
12'4"X 20'7" |
-- |
Call to Order |
-
Specifications
Heavy duty aluminum frame
Our standard greenhouse aluminum frame is ideal for hobby residential and commercial greenhouses that require a permanent structure which complements an existing landscape. The standard greenhouse frame can withstand 85 mph winds and 30 pounds per square foot for snow loads. Mix and match glazing to suit your growing needs.
Roof Slope: 5/12 pitch
Standard Widths: 6', 8', 10', 12' , 14',16', 18', 20'.
Standard Lengths: 6',8', 10', 12', 14', 16', 18', 20', 22', 24', 26', 28', 30', 32', 34', 36', 39', 41', 43', 45', 47', 49', 51',
Standard colors: A wet baked enamel paint in your choice of white, Hartford Green or Rideau Brown
*****Custom colors and sizes are available. Call us 1-800-531-4769 (toll free).
Greenhouse Includes
12 Eye Hooks for Hanging Baskets
One Maximum - Minimum Thermometer
DVD and Written Installation Instruction
Automatic Vent Openers for all Roof Vents
Wood Crating for protected - problem free shipping
-
Support
If you need additional technical support or have a question, we can be reached 8:30 AM to 5:30 PM central time, Monday through Friday at:
Phone: 800-531-4769 (toll-free US and Canada) or 251-471-5328
FAX: 251-471-5465
E-mail: info@gothicarchgreenhouses.net
-
Recommended Accessories
Side Vent: 24" x 24" side vent provides added ventilation to any greenhouse.
Click picture for more information & Price
Glass Louvres: A 24”x 28” aluminum frame with adjustable glass louvre blades. Can easily be installed in any greenhouse.
Click picture for more information & Price
Vent Screens:Specially designed to work in conjunction with our vents and automatic openers.
Click picture for more information & Price
Solar Powered Vent Opener:Greenhouse Accessories - Solar Powered Vent Opener
Take the guesswork out of your greenhouse ventilation. This opener will operate your vent based on temperature.
Click picture for more information & Price
Caframo Fan:Equalize the greenhouse temperature and distribute air evenly throughout. This quiet two-speed fan maintains constant air movement.
Click picture for more information & Price
Caframo Heater: Total climate control with 3 heat and 2 fan settings. Auto thermostat maintains a selected temperature. 5 year mfg's warranty. Ideal for smaller greenhouse
All Cedar Benches:Choose from two sizes of these heavy duty all cedar framed benches, with either a wire
Click picture for more information & Price
Cedar Benches With Wire Top:Choose from two sizes of these heavy duty all cedar framed benches, with either a wire top.
Click picture for more information & Price
Marley Heater: 220VOLT – 4KW An efficient fan-forced heater for larger size greenhouses. Controlled with an adjustable automatic thermostat.
Click picture for more information & Price
