System 2436S - 24' x 36' Package
|
Complete 24' x 36' frame - 15 gauge 2" square tube structure, 2" x 4" columns on 6' spacing. 8' sidewall height. (Plate Mount and Anchor Mounted available upon request there may be an additional cost)
2" x 15 gauge square tube metal endwall framing
Complete 8mm twinwall polycarbonate covering for roof, sidewalls, & endwalls
Two 3'-6" x 6'-8" ADA insulated steel door with 22" x 22" tempered glass and lockset
Two 24" exhaust fan - 1-speed, 1/2 HP, 115 V
One 27" Motorized Shutter
One 3' x 12' Evap Cooler
One 3' x 12' Versa-Vent
One 115,000 BTU Gas or LP Heater - vent kit with elbow and hanger kit
Two 20" Horizontal Air Flow Fans
Thermostatic Logic Controller
25# psf Snow Load 80# mph Wind load
|
Model# |
Size |
Price |
Buy Now |
System E2436S Package |
24' x 36' |
Call for price |
Call to Order |
System 2448S - 24' x 48' Package |
Complete 24' x 48' frame - 15 gauge 2" square tube structure, 2" x 4" columns on 6' spacing. 8' sidewall height. (Plate Mount and Anchor Mounted available upon request there will be an additional cost)
Complete 8mm twinwall polycarbonate covering for roof, sidewalls, & endwalls
Two 3'-6" x 6'-8" ADA insulated steel door with 22" x 22" tempered glass and lockset
Two 30J " exhaust fan - 1-speed 1/2 HP, 115 V
One 27" Motorized Shutter
One 3' x 15' Evap Cooler
One 3' x 15' Versa-Vent
One 145,000 BTU Gas or LP Heater - vent kit with elbow and hanger kit
Two 20" Horizontal Air Flow Fans
Thermostatic Logic Controller
25# psf Snow Load 80# mph Wind load
|
Model# |
Size |
Price |
Buy Now |
System 2448S - 24' x 48' |
24' x 48' |
Call for price |
Call to Order |
System 2460S - 24' x 60' |
Complete 24' x 60' frame - 15 gauge 2" square tube structure, 2" x 4" columns on 6' spacing. 8' sidewall height. (Plate Mount and Anchor Mounted available upon request there will be an additional cost)
2" x 15 gauge square tube metal endwall framing
Complete 8mm twinwall polycarbonate covering for roof, sidewalls, & endwalls
Two 3'-6" x 6'-8" ADA insulated steel door with 22" x 22" tempered glass and lockset
Two 36" exhaust fan - 1-speed, 1/2 HP, 115 V
One 27" Motorized Shutter
One 4' x 15' Evap Cooler
One 4' x 15' Versa-Vent
One 145,000 BTU Gas or LP Heater - vent kit with elbow and hanger kit
Two 20" Horizontal Air Flow Fans
Thermostatic Logic Controller
25# psf Snow Load 80# mph Wind load
|
Model# |
Size |
Price |
Buy Now |
System 2460S - 24' x 60' |
24' x 60' |
Call for price |
Call to Order |
System 2848S - 28 x 48'
|
Complete 28' x 48' frame - 15 gauge 2" square tube structure, 2" x 4" columns on 6' spacing. 8' sidewall height. (Plate Mount and Anchor Mounted available upon request there will be an additional cost)
2" x 15 gauge square tube metal endwall framing
Complete 8mm twinwall polycarbonate covering for roof, sidewalls, & endwalls
Two 3'-6" x 6'-8" ADA insulated steel door with 22" x 22" tempered glass and lockset
Two 30K" exhaust fan - 1-speed, 3/4HP, 115 V
One 33" Motorized Shutter
One 3' x 17' Evap Cooler )
One 3' x 17' Versa-Vent
One 145,000 BTU Gas or LP Heater - vent kit with elbow and hanger kit
Two 20" Horizontal Air Flow Fans
Thermostatic Logic Controller
20# psf Snow Load 80# mph Wind load
|
Model# |
Size |
Price |
Buy Now |
System 2848S - 28 x 48' |
28' x 48' |
Call for price |
Call to Order |
System 3048S - 30' x 48' |
Complete 30' x 48' frame - 15 gauge 2" square tube structure, 2" x 4" columns on 6' spacing. 8' sidewall height. (Plate Mount and Anchor Mounted available upon request there will be an additional cost)
2" x 15 gauge square tube metal endwall framing
Complete 8mm twinwall polycarbonate covering for roof, sidewalls, & endwalls
Two 3'-6" x 6'-8" ADA insulated steel door with 22" x 22" tempered glass and lockset
Two 36" exhaust fan - 1-speed & 2-speed, 1/2 HP, 115 V
One 33" Motorized Shutter
One 4' x 15' Evap Cooler
One 4' x 15' Versa-Vent
One 145,000 BTU Gas or LP Heater - vent kit with elbow and hanger kit
Two 20" Horizontal Air Flow Fans
Thermostatic Logic Controller
18# psf Snow Load 80# mph Wind load
|
Model# |
Size |
Price |
Buy Now |
System 3048S - 30' x 48' |
30' x 48' |
Call for price |
Call to Order |
System 3060S - 30' x 60'
|
Complete 30' x 60' frame - 15 gauge 2" square tube structure, 2" x 4" columns on 6' spacing. 8' sidewall height. (Plate Mount and Anchor Mounted available upon request there will be an additional cost)
2" x 15 gauge square tube metal endwall framing
Complete 8mm twinwall polycarbonate covering for roof, sidewalls, & endwalls
Two 3'-6" x 6'-8" ADA insulated steel door with 22" x 22" tempered glass and lockset
Two 42" exhaust fan - 1-speed, 1/2 HP, 115 V
One 33" Motorized Shutter
One 5' x 15' Evap Cooler
One 5' x 15' Versa-Vent
One 175,000 BTU Gas or LP Heater - vent kit with elbow and hanger kit
Two 20" Horizontal Air Flow Fans
Thermostatic Logic Controller
18# psf Snow Load 80# mph Wind load
|
Model# |
Size |
Price |
Buy Now |
System 3060S - 30' x 60' |
30' x 60' |
Call for price |
Call to Order |
System 3060S - 30' x 72'
|
Complete 30' x 72' frame - 15 gauge 2" square tube structure, 2" x 4" columns on 6' spacing. 8' sidewall height. (Plate Mount and Anchor Mounted available upon request there will be an additional cost)
2" x 15 gauge square tube metal endwall framing
Complete 8mm twinwall polycarbonate covering for roof, sidewalls, & endwalls
Two 3'-6" x 6'-8" ADA insulated steel door with 22" x 22" tempered glass and lockset
Two 48" exhaust fan - 1-speed, 1/2 HP, 115 V
One 33" Motorized Shutter
One 6' x 15' Evap Cooler
One 6' x 15' Versa-Vent
One 200,000 BTU Gas or LP Heater - vent kit with elbow and hanger kit
Four 20" Horizontal Air Flow Fans
Thermostatic Logic Controller
18# psf Snow Load 80# mph Wind load
|
Model# |
Size |
Price |
Buy Now |
System 3072S - 30' x 72' |
30' x 72' |
Call for price |
Call to Order |
