Insect Screens Greenhouses-Copyright by Gothic Arch Greenhouses


  • Made of high tensile-strength round polyethylene monofilaments.Insect Screens

  • UV stabilized

  • Transparent

  • Unique structure results in maximized air circulation, to enable higher yields

  • Lightweight and easy to install

  • Strong woven and tucked in selvages - even if mechanically punctured, the screen will keep its strength and stability

  • Easily cleaned with power sprayers by back flushing

  • Our insect screens, correctly installed, prevent penetration, yet provide maximum possible air flow essential for optimal crop yields. Regardless of the cooling and ventilation system that you use, you need to consider insect screen.

  • ANTI-VIRUS INSECT SCREEN excludes Whitefly, Aphids, Leaf miners and up to 80% of Western Flower Thrips in field applications.

  • NO-THRIPS INSECT SCREEN is designed to exclude Thrips and other pests, and is the material of choice where Thrips exclusion is priority.

Given the increased problems and costs associated with pesticides, no modern greenhouse should be without the properInsect Screens insect barrier. Insect Screens, correctly installed, prevent insect penetration, yet provide maximum possible air flow, essential for optimal crop yields.

Regardless of the cooling and ventilating system that you use, you need to consider insect screen. Screening intake vents will produce dramatic results, but all greenhouse openings, including service doors (which should incorporate double screened doors), should be screened for best results .

Insect Screen excludes White fly, Aphids, Leaf miners and up to 80% of  Western Flower Thrips in field applications. Several years of laboratory and field testing have resulted in a patented screen structure that maximizes air circulation, while keeping pests out. Special equipment has been developed to ensure hole size accuracy, and a 0.24 mm diameter yarn is used, which is 45% stronger with greater UV resistance, compared to 0.20 mm diameter standard yarns.



Specification

  Vector Virus No Thrips
Construction 50 x 24 mesh 81 x 81 mesh
Opening Size 0.0105 x 0.0322" 0.0059 x 0.0059"
Thread Size 0.24 mm 0.15 mm
Weave 1/1 1/1
Weight 0.33 lbs/yd squared 0.216 lbs/yd squared
Shade Value 20% 33%
Light Transmission 80% 66%
Standard Width 39", 78", 118", 137" 55", 78"
Maximum Length 656 feet 328 feet
UV Resistance Tested to equivalent of 5 years Tested to equivalent


Prices

Description Width Max Length Weight Per sf
G04-AV (Anti-Virus) 39", 78", 118", 137" , 138" 177".0. 656 ft. 0.037 lbs. / sq. ft. $0.78
G04-NT (No Thrips ) 134" 328 ft. 0.024 lbs./ sq. ft. $0.84


Seaming:  $.25 per linear foot (When two pieces of cloth have to be sewed together)

Taping: $.25 per linear foot (To go along the perimeter of the cloth for reinforcement also required for brass grommets)

Brass Grommets: $.20 each (Can be placed however far apart you would like. Perimeter taping is required.)

Clip-On Grommets:  $.25 each Clip-On grommets that can be used on the cloth whether it is taped on the edges or not.

****There is a $20.00 fee for orders less than $100.00.

Installation


1. Check that the frame, structure or wall to which the insect screen will be fastened is as square as possible, to eliminate twisting or shortage of fabric.

2. Metal parts should not touch the screen. In the summer, heat accumulates in metal parts, and might damage the plastic screen. Therefore, it is important to cover metal parts with white water based latex paint or white tape to protect the screen.

3. When you install the screen, keep the screen square and parallel to the sides of the greenhouse. This will keep the fibers of the screen parallel. If the fibers are not parallel to the greenhouse sides, the screen will be shortened in length and in width.

4. When you install several screens together which have not been stitched, you should connect the first screen to the sides of the greenhouse. Then, connect the second screen to the first one and to the greenhouse sides.
