IL2-MS - Irrigation Moisture
Switch |
|
 The
Irrigation Moisture Switch, IL2-MS, is a unique new product
that easily controls irrigation by an accurate measurement of
soil moisture. Irrigation for landscapes, trees, crops
or vegetables is scheduled only when water is needed so water
bills may be reduced 30 to 50%. Irrigation with advanced
timing controls handle multiple schedules, but the controllers
need an automatic shut off when water is being wasted.
Typically an irrigation controller schedule is not aware of
saturated soil conditions caused by rain or over-watering.
Over watering plants causes root rot, lack of oxygen, and
disease. Water runoff and leaching not only wastes money
but often wastes drinking water, fertilizer and damages the
environment. The average homeowner, large of small
business does not waste time adjusting irrigation schedules
because the IL2-MS Moisture Switch kit handles watering
automatically.
IL2-MSTM
Kit Benefits
Saves money, can
reduce 1/2 to 1/3 off a water bill
Beautiful
landscapes have enough water - no stress
Healthy lawns -
never too much water applied
Absolutely no
maintenance, all electronic
Precise moisture
set point adjustment
Saves time, no
worries about changing schedules
The IL2-MSTM helps all existing controllers
since they do not monitor actual moisture conditions, weather,
and are not automatically adjusted by plant water need. The
sensor is plugged into the soil and buried in the root zone
where water is needed. The Moisture Switch regulates water
applied by continuously monitoring the soil condition at the
sensor, and interrupts the controller schedule when enough
water reaches the plant roots. As soon as the soil dries out
below the recommended set point, an internal switch closes
that signals the controller to continue irrigation as needed.
The Moisture Switch box comes with normally closed, normally
open, and separate hot or neutral outputs making several
connection options easy and reliable.
Controller
Applications - Functions
Easy for new
controllers or upgrades to existing systems
Connects to basic
timers or sophisticated controllers
Works with or
without a rain switch input
Regulate up to 10
valves, or one multi-station system directly
Independently drip
irrigate (microirrigation) without a timer
Configures as an
alarm system
Status signal to a
central controller
Direct alarm by
beacon light - "Water me!" Flasher
Sealed enclosure is
water proof for outdoors
Internal fuse
protection and UL rated relay
Volt Meter Required
|
|
Specifications
for IL2-MSTM Kit
|
Enclosure
Water proof, weather resistant, IP 66.
Fiberglass reinforced polycarbonate, noncorrosive
Rated for indoor only. |
Moisture Switch Set Point Range
0-1V
0-60% Volumetric Soil Moisture
Water over Lo - 1.5%, Hi - 3% - jumper select |
Dimensions - Weight
W x L x D: 3.5" x 5" x 3"
0.6 lbs. without sensor or cables |
Fuses
10 A (2 ea) - Automotive type for H. and N.
1 A (1 ea) - Automotive type for internal power. |
System Power
Relay Open: 2.2 VA
Relay Closed: 2.4 VA |
Operating Input Rating
24-28 V AC, 60 Hz, 10A, Class II Circuit Only
May be factory converted to 12 V DC operation.
|
Relay Controls
Six Outputs:
Normally Open - Hot, Neutral
Normally Closed - Hot, Neutral
Common - Hot, Neutral
Max Contact Cur. @ 28V AC - 10 A. |
Sensors
IL2: Millivolt signal (0-1 V). 65 ft. Cable - 4 wire.
Volumetric soil moisture range 0-60 % |
Controls Capacity
10 control valve solenoids, 1.0 A ea. |
|
|
Price $ 475.00 |
|
|
|
TH2O
- Soil Moisture
Meter |
|
The
TH 2O
is the new way to measure
volumetric soil moisture content. TH2O
combines ease of use, accuracy, and low cost. Growers,
turf specialists, and scientists receive immediate precise
soil moisture data. The TH2O
takes accurate soil moisture samples with minimal disturbance.
By simply inserting the probe into the ground, actual soil
moisture percentage readings are given. Watering needs
can be quickly determined making it easy to remove the
guesswork and errors.
How does it work?
The sensor sends a
microwave signal and analyzes the reflection to measure the
dielectric constant (theta) of the soil. The dielectric
reading is then converted to volumetric water content (+/-1%
accuracy). The battery powered hand held readout
provides instantaneous readings for mineral or organic soils.
How do you use it?
The TH20 probe is inserted into
the soil and when the readout button is pushed the LCD shows
the soil water content as a decimal value.
You may also install access
tubes and take soil moisture reading from deep within the
soil profile.
The TH 2O
Benefits:
S ealed
probes
Fast response
Variable depth extension tubes
|
|
Specifications for TH2O Sensor |
Specifications for TH2O Meter |
|
Accuracy |
+/- 2% soil
moisture (+/-0.02 m3/m3)
with factory calibration |
|
Power Input |
5-15 VDC at 19 mA
Output: 0-1 VDC for: 0-50% |
|
Rod Dimensions |
2.375" (60 mm), |
|
Overall length |
8" including pins |
|
Extensions |
Choice of 50 cm or 100
cm (may be joined)
For convenient walking
about with probes. Fits into 2 in ID access tubes to
deeper vadose zone. |
|
Patents |
EUR 963703190.1, GB
9609372.9 USA 08\706675 Pend. |
Price $ 1,095.00 |
|
Display |
16 x 2 character
LCD |
| Soil
moisture ranges |
zero to saturation.
0-1V on voltage range |
|
Battery life |
Typically: 6500
readings for ThetaProbe type ML2x: 4500 readings
fore Profile Probe type PR1/6 |
| Size/Weight |
150 x 80 40mm, 450g |
| Battery |
9V Alkaline Cell
(PP3) |
|
|
Waterproof pH Tester |
|
The Waterproof pH Tester has a 2
point manual calibration ± 0.1 pH accuracy, range:0.0 to 14.0
pH, replaceable MA73600 pH electrode with battery technology
providing 1500 hours of battery life.
|
|
Model # |
Description |
Price |
Purchase |
|
NGW-716600 |
pH51
Waterproof |
$ 73.95 |
|
|
NGW-716601 |
MA73600
replacement probe for pH51 |
$ 46.95 |
|
|
NGW-722300 |
MA9004 -
220ml 4.01 buffer solution |
$ 10.95 |
|
|
NGW-722305 |
MA9007 -
220ml 7.01 buffer solution |
$ 10.95 |
|
|
NGW-722310 |
MA9015 -
220ml storage solution for pH electrode |
$ 10.95 |
|
|
NGW-722315 |
MA9016 -
220ml probe cleaning solution |
$ 10.95 |
|
|
NGW-716301 |
M10004B -
20ml packet 4.01 buffer solution - case only 25/case |
$ 25.00 |
|
|
NGW-716306 |
M10007B -
20ml packet 7.01 buffer solution - case only 25/case |
$ 25.00 |
|
|
Waterproof TDS Tester |
|
The waterproof TDS tester has
automatic temperature compensation and 1 point manual
calibration range:0.0 to 1999 ppm (mg/L), replaceable MA73075
probe.
|
|
Model # |
Description |
Price |
Purchase |
|
NGW-716605 |
T75
waterproof TDS tester |
$ 76.95 |
|
|
NGW-716606 |
MA73075
replacement probe for T75 |
$ 52.95 |
|
|
NGW-722325 |
MA9062 -
220ml 1382 ppm TDS solution |
$ 10.95 |
|
|
NGW-722326 |
MA10032B -
20ml packet 1382 ppm TDS solution - case only 25/case |
$ 25.00 |
|
|
Waterproof EC Tester |
|
The waterproof conductivity tester has
automatic temperature compensation and 1 point manual
calibration range: 0 to 1999 µS/cm, replaceable MA73076
probe.
|
|
Model # |
Description |
Price |
Purchase |
|
NGW-716630 |
C65
waterproof EC tester |
$ 76.95 |
|
|
NGW-716611 |
MA73076
replacement probe for C65 |
$ 52.95 |
|
|
NGW-722340 |
MA9061 -
220ml 1413 µS/cm EC solution |
$ 10.95 |
|
|
NGW-722341 |
MA10031B -
20ml packet 1413 µS/cm
solution - case only 25/case |
$ 25.00 |
|
|
pH Monitor |
|
 Model SMS110
pH Monitor range: 0.0 to 14.0 pH,
with 2 point manual calibration, and accuracy of ±0.2 pH. Set
point range: 3.5 to 7.5 pH, and led visual alarm active when
reading is higher than set point. Supplied with 12v DC power
adapter, MA911B/2 double junction pH electrode, 20ml pH 7.01
buffer solution and screwdriver for calibration.
|
|
Model # |
Description |
Price |
Purchase |
|
NGW-716660 |
SMS110 pH
monitor |
$ 110.95 |
|
|
NGW-716661 |
MA911B/2
replacement probe for SMS110 |
$ 54.95 |
|
|
NGW-722300 |
MA9004 -
220ml 4.01 buffer solution |
$ 10.95 |
|
|
NGW-722305 |
MA9007 -
220ml 7.01 buffer solution |
$ 10.95 |
|
|
NGW-722310 |
MA9015 -
220ml storage solution for pH electrode |
$ 10.95 |
|
|
NGW-722315 |
MA9016 -
220ml probe cleaning solution |
$ 10.95 |
|
|
NGW-716301 |
M10004B -
20ml packet 4.01 buffer solution - case only 25/case |
$ 25.00 |
|
|
NGW-716306 |
M10007B -
20ml packet 7.01 buffer solution - case only 25/case |
$ 25.00 |
|
|
TDS Monitor |
|
Model SMS410
TDS Monitor range: 0-1990 ppm,
with 1 point manual calibration, and accuracy of ± 2% full
scale and automatic temperature compensation. Set point range:
700 to 1800 ppm, and led visual alarm active when reading is
lower than set point. Supplied with 12v DC power adapter,
MA812B/2 conductivity probe, 20ml 1500 ppm buffer solution and
screwdriver for calibration.
|
|
Model # |
Description |
Price |
Purchase |
|
NGW-716650 |
SMS410 TDS
monitor |
$ 110.95 |
|
|
NGW-706651 |
MA812D/2
replacement probe for SMS410 |
$ 49.95 |
|
|
NGW-722300 |
MA10442B -
20ml packet 1500 ppm solution - case only 25/case |
$ 25.00 |
|
|
Portable pH Meter |
|
Model SM100
pH meter, range: 0.0 to 14.0, with
2 point manual calibration, and accuracy of ± 0.2 pH. Supplied
with a MA911B/1 double junction pH electrode, 9v battery, 20ml
pH 7.01 packet buffer solution and screwdriver for
calibration.
|
|
Model # |
Description |
Price |
Purchase |
|
NGW-716665 |
SM100
Portable pH meter |
$ 106.95 |
|
|
NGW-716666 |
MA911B/1
replacement probe for SM100 |
$ 54.95 |
|
|
NGW-722300 |
MA9004 -
220ml 4.01 buffer solution |
$ 10.95 |
|
|
NGW-722305 |
MA9007 -
220ml 7.01 buffer solution |
$ 10.95 |
|
|
NGW-722310 |
MA9015 -
220ml storage solution for pH electrode |
$ 10.95 |
|
|
NGW-722315 |
MA9016 -
220ml probe cleaning solution |
$ 10.95 |
|
|
NGW-716301 |
M10004B -
20ml packet 4.01 buffer solution - case only 25/case |
$ 25.00 |
|
|
NGW-716306 |
M10007B -
20ml packet 7.01 buffer solution - case only 25/case |
$ 25.00 |
|
|
Portable TDS Meter |
|
Model SM401
TDS meter - Range: 0.0 - 1990 ppm
- with automatic temperature compensation and 1 point manual
calibration supplied with MA811D/1 TDS probe, 9v battery, 20ml
1382 ppm packet buffer solution and screwdriver for
calibration.
|
|
Model # |
Description |
Price |
Purchase |
|
NGW-716655 |
SM401
Portable TDS meter |
$ 101.95 |
|
|
NGW-716656 |
MA811D/1
replacement probe for SM401 |
$ 49.95 |
|
|
NGW-722325 |
MA9062 -
220ml 1382 ppm TDS solution |
$ 10.95 |
|
|
NGW-722326 |
M10032B -
20ml packet 1382 ppm TDS solution - case only 25/case |
$ 25.00 |
|
|
Smart pH/EC/TDS Combination
Meter |
|
Model SM802
Smart pH/EC/TDS combination meter,
range: 0.00 to 14.00 pH, 0 - 4000 ppm, 0.00 - 6.00 mS/cm,
accuracy of ±0.20 pH and ±2% full scale for EC and TDS.
Supplied with a MA850 combination electrode, 9v battery, 20ml
packet buffer solution of pH 7.01, 1500 ppm and 1413 µS/cm.
|
|
Model # |
Description |
Price |
Purchase |
|
NGW-716615 |
SM802 smart
pH/TDS/EC combination meter |
$ 227.95 |
|
|
NGW-716616 |
MA850
replacement probe for SM802 |
$ 79.95 |
|
|
NGW-722300 |
MA9004 -
220ml 4.01 buffer solution |
$ 10.95 |
|
|
NGW-722305 |
MA9007 -
220ml 7.01 buffer solution |
$ 10.95 |
|
|
NGW-716301 |
M10004B -
20ml packet 4.01 buffer solution - case only 25/case |
$ 25.00 |
|
|
NGW-716306 |
M10007B -
20ml packet 7.01 buffer solution - case only 25/case |
$ 25.00 |
|
|
NGW-722346 |
M10442B -
20ml packet 1500 ppm TDS solution - case only 25/case |
$ 25.00 |
|
|
NGW-722340 |
MA9061 - 220
ml 1413 µS/cm EC solution |
$ 10.95 |
|
|
NGW-722341 |
M10031B -
20ml packet 1413 µS/cm EC solution - case only 25/case |
$ 25.00 |
|
|
Smart pH Meter with Cal Test |
|
 Model
SMS115
pH meter with cal-test, range: 0.0
to 14.0 pH, accuracy of ± 0.2 pH, manual calibration in 2
points. Supplied with 12v DC power adapter, MA912B/2 pH
electrode, 20ml packet of cal-test solution, 4.01 solution,
7.01 solution, storage solution and screwdriver for
calibration.
|
|
Model # |
Description |
Price |
Purchase |
|
NGW-716635 |
SMS115 smart
pH meter with cal test |
$ 100.95 |
|
|
NGW-716636 |
MA915B
replacement probe for SMS115 |
$ 79.95 |
|
|
NGW-722300 |
MA9004 -
220ml 4.01 buffer solution |
$ 10.95 |
|
|
NGW-722305 |
MA9007 -
220ml 7.01 buffer solution |
$ 10.95 |
|
|
NGW-722310 |
MA9015 -
220ml storage solution for pH electrode |
$ 10.95 |
|
|
NGW-722315 |
MA9016 -
220ml probe cleaning solution |
$ 10.95 |
|
|
NGW-716301 |
M10004B -
20ml packet 4.01 buffer solution - case only 25/case |
$ 25.00 |
|
|
NGW-716306 |
M10007B -
20ml packet 7.01 buffer solution - case only 25/case |
$ 25.00 |
|
NGW-
|
Sugar Refractometer ATC |
|
Model MR32
Sugar refractometer for general
purpose with ATC. Range 0 - 32% brix, resolution 0.1%. Use
this item to gauge the health of your plants by measuring
their sugar content. This method is used by horticulturalists
to indicate plant stress before the plant shows symptoms.
Simple to use - just extract one drop of liquid from the
petiole tissue (leaf stem) & easily measure sugar content.
|
|
Model # |
Description |
Price |
Purchase |
|
NGW-716695 |
MR32 Sugar
Refractometer ATC |
$ 116.95 |
|
|
Bluelab pH Truncheon Meter |
|
With it’s easy to
read illuminated display, one-touch calibration system, super
clear instructions and no buttons to push, measuring pH just
got a whole lot simpler. The flashing lights you love so much;
the easiest calibration system ever; reliability only Bluelab
products can provide; longest lasting probe on the market AND
it’s replaceable; auto on just like the Bluelab Truncheon;
Automatic Temperature Compensation; a scale of 2.0pH - 10.9
pH.
|
|
Model # |
Description |
Price |
Purchase |
|
NGW-716051 |
Truncheon
Meter |
$ 199.95 |
|
|
Bluelab Original Truncheon
Meter |
|
Features of this reliable meter
include: EC, CF and ppm scales, factory calibrated, fully
waterproof, auto turn on and off. It is powered by three
standard AA batteries. There are no external switches or
adjustment knobs.
∙Reliable!
∙Easy to Use!
∙No calibration required
| | | |
Hobby
